Buyers in Bahrain use Samvay instrumentation tube fittings across refining at Sitra, aluminium smelting and petrochemicals, all machined and tested at our Ahmedabad works. Bahrain's refinery modernisation and aluminium smelting need corrosion resistant instrument connections.
Instrumentation tube fittings use a front and back ferrule to grip and seal tubing without welding, giving a leak tight, vibration resistant joint that can be remade many times during maintenance. In Bahrain the typical service is saline coastal climate and refinery service, so grade selection and documentation matter as much as price. Every order ships with heat traceable material and a test record.
Instrumentation Tube Fittings for industries in Bahrain
Control and sampling tubing on skids and instrument panels.
Hydraulic and pneumatic control tubing on heavy equipment.
Impulse lines from tapping points to transmitters and analysers.
Instrument and control tubing on vessels and offshore units.
Choosing the right grade in Bahrain
Service conditions in Bahrain usually mean saline coastal climate and refinery service. These are the grades we most often supply for that duty.
| Recommended grade | Why it suits Bahrain |
|---|---|
| Super duplex 2507 or S32760 | High chloride air and seawater, where PREN above 40 resists pitting and crevice corrosion |
| Duplex 2205 or Inconel 625 to NACE MR0175 | Sour hydrocarbon service, where hardness control and sulphide stress cracking resistance are required |
| Hastelloy C276 or Monel 400 | Aggressive acids, chlorinated media and effluent where stainless steel would pit |
Instrumentation Tube Fittings specifications
| Types | Tube to Female, Instrument Pipe Fittings, Tube to Union, Accessories, Tube to Male |
|---|---|
| Equivalent To | DK-LOK, PARKER, SWAGELOK, HOKE |
| Standard | ASME SA-479, Type 304-SS, BS 970 304S11, DIN 4401, ASTM A276 Type 304 |
| Sizes | 1/8’’ to 2’’ and 3mm to 50mm |
| Ends | Threaded, Welding, JIC |
| Pressure Rating | 1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
| Threads | NPT , BSPT, BSPP |
| Specification | Items Made from Hex, ASTM A276; Items made from Round Bar- ASTM A182 |
| HS CODE | 73072900 |
Instrumentation Tube Fittings we supply in Bahrain
Standards and documents for projects in Bahrain
- Bapco specifications
- NACE MR0175
- ASME B31.3
- Positive material identification and hydrostatic test reports on request
- Packing lists, origin certificates and HS code 73072900 or 84818030 on every invoice
Delivery to Bahrain
We deliver by sea from Mundra or Nhava Sheva to Khalifa Bin Salman Port in about 7 to 9 days. Our regular delivery points include:
- Sitra
- Hidd
- Askar
Frequently asked questions
How do instrumentation tube fittings reach Bahrain from India?
Yes. We ship by sea from Mundra or Nhava Sheva to Khalifa Bin Salman Port in about 7 to 9 days. Regular consignments reach Sitra, Hidd and Askar, and mixed orders of valves, fittings and accessories can be consolidated into one shipment with a single set of documents.
Which material grade do you recommend for projects in Bahrain?
For high chloride air and seawater, where PREN above 40 resists pitting and crevice corrosion, we usually recommend Super duplex 2507 or S32760. Where conditions are milder, Duplex 2205 or Inconel 625 to NACE MR0175 is a cost effective alternative. Share your process data and we will confirm the grade before quoting.
What certificates come with orders for Bahrain?
Orders for Bahrain are supplied to Bapco specifications, NACE MR0175 and ASME B31.3. Every part is heat marked and traceable to its mill certificate, and third party inspection by the agency of your choice can be arranged before dispatch.
Are your tube fittings interchangeable with other double ferrule brands?
Our double ferrule design follows the established geometry used by the leading instrument fitting brands, and the fittings are available from 1/8 inch to 2 inch and 3 mm to 50 mm, rated up to 10000 psi depending on tube wall, with male, female, union, reducer and bulkhead configurations. For mixed brand installations on sites in Bahrain we still recommend using ferrules and nuts from one supplier on each joint.
How do I request a quote for Bahrain?
Email your item list with sizes, grade, quantity and delivery point to sales@samvayglobal.com or message us on WhatsApp at +91 77389 26862. We reply within one working day with price, lead time and shipping terms for Bahrain.
